| PART # | ROD CORE | INDUCTANCE @1KHZ 0.3V (µH) |
DC RESISTANCE @20°C (MΩ) (MAX) |
RATED CURRENT (RMS) (A) |
A (MAX) | B (MAX) | C (MAX) |
|---|---|---|---|---|---|---|---|
| 004502 | 5x12 | 3.3±20% | 20.0 | 1.5 | 8 | 20 | 7.5±1.5 |
| 075002 | 5x12 | 1.0±20% | 3.5 | 5.0 | 10 | 25 | 10.0±1.5 |
| 004904 | 5x20 | 3.3±20% | 13.0 | 3.0 | 9 | 25 | 10.0±1.5 |
| 025402 | 5x20 | 3.3±20% | 7.0 | 6.0 | 10 | 25 | 7.5±1.5 |
| 015901 | 5x20 | 7.5±20% | 30.0 | 1.5 | 8 | 20 | 12.5±2.0 |
| 076602 | 5x20 | 5.0±20% | 12.0 | 3.0 | 9 | 25 | 10.0±1.5 |
| 068102 | 6x32 | 10.0±20% | 45.0 | 3.0 | 11 | 40 | 11.0±2.0 |
| 084002 | 6x32 | 10.0±20% | 8.0 | 8.0 | 12 | 40 | 10.0±1.5 |
| 044701 | 10x30 | 5.0±20% | 6.0 | 10.0 | 15 | 35 | 12.5±2.0 |
