In this section, we have listed core and bobbin geometries that are most commonly used to build switching transformers. Do reach out to us if you need a specific size that isn't listed here. You may use the data provided to finalize the transformer design and request a quote and samples. Footprint data provided is subject to change so check with us before you finalize your PCB layout on this basis.
| OPTIONS | A |
|---|---|
| Option 1 | 3.0±0.5 |
| Option 2 | 4.5±0.5 |
| Winding Width | 9mm |
| Winding Height | 2.5mm |
| Core Ae | 19.3sq.mm |
| Core Le | 55.6mm |
