| PART # | DRUM CORE | INDUCTANCE @1KHZ 0.3V (µH) |
DC RESISTANCE @200°C (MΩ) (MAX) |
RATED CURRENT (RMS) (MA) |
|---|---|---|---|---|
| 059802 | 6x8 | 3.3±20% | 25 | 1000 |
| 107601 | 6x8 | 5.5±20% | 30 | 750 |
| 044202 | 6x8 | 10.0±20% | 60 | 1000 |
| 126001 | 6x8 | 13.0±20% | 45 | 1200 |
| 059701 | 6x8 | 15.0±20% | 110 | 500 |
| 095602 | 6x8 | 100.0±20% | 355 | 300 |
| 026802 | 6x8 | 800.0±20% | 3300 | 150 |
