| PART # | INDUCTANCE (mH) (MIN) |
CURRENT RATING (mA) (STEADY STATE) |
LEAK INDUCTANCE (µH) (TYPICAL) |
DC RESISTANCE (Ω) (MAX) |
|---|---|---|---|---|
| 088001 | 3.30 | 2.50 | 65 | 0.120 |
| 088101 | 8.20 | 2.00 | 120 | 0.200 |
| 088201 | 12.00 | 1.50 | 312 | 0.450 |
| 088301 | 18.00 | 1.25 | 208 | 0.315 |
| 100601 | 22.00 | 1.00 | 375 | 0.550 |
| 088401 | 27.00 | 1.00 | 394 | 0.600 |
| 100701 | 33.00 | 0.75 | 750 | 0.925 |
| 088501 | 47.00 | 0.75 | 789 | 1.080 |
| Isolation | At 50Hz / 4mA / 1 min |
| Between windings | 1500V AC |
| Windings to core | 1500V AC |
| Insulation Resistance | At 500V DC Greater than 100MΩ |
